Application of pet film, glass, paper, pvd, floor film coating and printing field.
Nitrogen(N2) Purge improve the quality of UV Curing.
Prohibit the inflow of oxygen from outside (prevent oxidation of product's surface).
Adopt special quartz window.
Prolong lamp's life time by preventing contamination of lamp and reflector, and prevent uv energy loss.
Cost down effect by using less amount of nitrogen gas.
Easy lamp exchange by applied sliding type's lamp housing.
Adopt cold mirror and hot mirror.
Uv lamps : medium/high pressure mercury and metal halide lamp(3~16KW).
Forced air cooling system.
Width of curing : 200~1,500mm
|
Length of Conveyor
|
2,000~4,000mm
|
|
|
|
Width of Conveyor
|
200~1,500mm
|
|
|
|
UV Lamp Q'ty
|
2~4 (Mercury, Metal Halide)
|
