ZDFB-1600/1300 Automatic honeycomb paper board making machine

A.Main Technical Parameter

1,Max core width≤1600mm(before expanding)

2,Core cutting thickness:8 to 80mm

3,Core cutting speed:less than 200times/min 4,Heating way:electrical heating, heated air circulation

5,Power:130KW

6,Board max width≤1300mm

7,Max board thickness≤80mm

8,Board production speed:≤15 m/min

9,Dimension:65000X 4200X 2900mm

10,Operating person request:3 to  5

B.process:

Paper loading in multi rollers     gluing       laminating       drying       cross cut    auto gathering and transmission      core expanding         drying          core and surface paper gluing      core and surface paper laminating        drying      cold pressing      cut off        collecting
