Specifications
|
|
|
|
Print specification
|
|
Print Head Set
|
SG1024 S/C 10PL
|
|
Color
|
4cX2/ (4c+w) X2/ 6cX2/ (6c+w)X2
|
|
Print Mode
|
Test: 195/157 m2/h
|
|
Draft: 102/85 m2/h
|
|
Normal:51/42 m2/h
|
|
Enhanced:25/20m2/h
|
|
Print size
|
|
Max Printing Size
|
5000/3200 mm
|
|
Max Material Size
|
5150/3260mm
|
|
Max material weight
|
450/340 kg/roll
|
|
Max material thickness
|
Up to 1 mm
|
|
Feeding system
|
Roll to roll
|
|
Type of ink
|
UV ink
|
|
Heating system
|
UV curing
|
|
Job format
|
The system works with PostScript R3TM, including EPS, TIFF, JPG, etc.
|
|
RIP system
|
Caldera
|
|
Power
|
Machine: 380 V ± 10%, three phases, 50/60Hz,
|
|
Maximum power
|
Machine: 10KW three phases
|
|
Dimension
|
8730 (L)X1500(W)*1920(H)/6930 (L)X1410(W)X1910(H) mm
|
|
Min. work area
|
10730 (L)X4410(W)*2800(H)/8930X4410(W)X2800(H) mm
|
|
Work station configuration
|
I5-3470/8G/1TB/DVD
|
|
|
Shanghai Teckwin Technology Development Co., Ltd was founded in
December 2001 in Shanghai, China. The company designs, manufactures and
sells the digital inkjet ceramic printer, grand format solvent UV
flatbed and roll-to-roll inkjet printing systems for the most demanding
graphics applications.
To utilize the most reliable components and with innovative
engineering based on a perfect manufacturing process is our goal.
Teckwin has its partners in USA and Germany. Our field
engineers are based in Europe, the Americas and Asia-Pacific Regions. An
extensive distribution network covers more than 75 countries in the
world. Our printers offers unparalleled value and superior printing
performance. In keeping with this goal, the company has achieved ISO
9001: 2008 Quality Management System Certification. Additionally, all
launched Teckwin products are CE certified.
