Developed for the direct printing of corrugated cardboard, with integrated compressible layer. For all common types of corrugated cardboards.
Roll material
"Peel off" print layer
Overall dimensional stability
Integrated compressible Layer*
High-resolution engraving
Consistent print
Optimized for water-based inks
Long lifetime / less abrasion
Improved ink laydown
* starting at 2.84 mm material thickness
|
Technical Data
|
|
Printing surface
|
Color: SBR / gray
Surface: ground
Roughness RZ (DIN 4768): 12.0 μm
Roughness RA (DIN 4768): 1.9 μm
Surface hardness (DIN 53505): 40° Shore A
|
|
Compressibility
|
With 135 N/cm2 ≥ 0.9 mm
|
|
Carrier
|
Calibrated foil
|
|
Nominal thickness (ISO 12636)
|
2.84 to 4.2 mm ± 0.02 mm
|
A leading manufacturer and supplier of printing blankets, ContiTech has expanded its offer – and now offers individual solutions in the flexographic areas as well.
The fresh commitment to a growing market is backed up by core competence in the area of elastomer technology. ContiTech now develops and manufactures innovative plate technology on this basis for trade shops and printers. As a business unit within the ContiTech division, we can make targeted use of the interdisciplinary know-how of a leading global rubber specialist. What is more, as a division of Continental AG, ContiTech also benefits from the commercial strength of an internationally successful corporation.
Synergies and development partnerships within the corporation make it possible for us to remain particularly close to markets and customers. With manufacturing plants making parallel products, it is also possible to avoid production bottlenecks. Above and beyond this, ContiTech works together closely with the leading technology movers in the field of hightech laser engraving products.
These are up to mastering the most difficult challenges in flexo printing. Our worldwide service network ensures that we remain as close as possible to the customer.
